Contrast Ratio :  1,100:1
Panel Technology :  IPS
Color Gamut :  NTSC 65%
Viewing Angle(H x V) :  178 x 178
Color Depth :  10bit, 1.07Billion colors
Response Time :  8 ms (G to G)
Surface Treatment(Haze) :  Anti Glare, 7H(Mohs)
Life time :  30,000 Hrs (Min.)
Operation Hours (Hours/Day) :  16/7

CONNECTIVITY(JACK INTERFACE)

Input - Digital - HDMI :  Yes (3), HDCP2.2/1.4
Input - Analog - RGB :  Yes (1)
Input - Audio In :  Yes (1)
Input - RS232C IN :  Yes (1)
Input - RJ45(LAN) :  Yes (1)
Input - USB :  USB3.0 Type A(3), USB2.0 Type A(3)
Output - DP Out :  No, HDMI Out (1)
Output - Audio Out :  Yes (1), Optical Yes (1)
Output - Touch USB :  Yes(2)

MECHANICAL SPECIFICATION

Bezel Color :  Black
Bezel Width :  17.7/17.7/17.7/45.7mm
Weight(Head) 86",75", 65" :  67Kg, 53Kg, 40Kg

EASY CONNECTION & SHARING

ScreenShare Pro Upgrade

With the newly upgraded ScreenShare Pro, which enables to show a maximum of six shared screens or a file on a screen in real-time, it has enhanced usability by allowing users to share Chromecast mirroring on the same network without any application.

Air Class

Air Class supports connecting up to 30 students and offers interactive meetings for all mobile devices on the same network, providing a variety of tools such as voting, answering, and sharing project texts.

USER FRIENDLY EXPERIENCE

Display Power Management

By activating DPM function, the display can be set to be on only when there is an input signal, which enables more efficient power management.

Annotation Upgrade

At annotation tool mode, ‘Un-do’ and ‘Re-do’ functions provide enhanced user experience. (Annotation tool can be used on any source.)

Web Browser

The TR3BF/G series supports the web browser in the Android OS, so you can search the web easily and quickly, without connecting to an external desktop.

All-in One

The TR3BF/G series integrates both Android OS and Free apps into a high performance SoC, without a PC.

SECURITY & COMPATIBILITY

Built-in OPS Slot

The TR3BF/G series supports OPS slots, allowing you to easily and conveniently mount OPS desktop at the back of the digital board without the hassle of connecting to an external desktop, offering you more expanded functions.

Google CTS* Pass

LG Interactive Display was granted an approval for Google's Compatibility Test Suite, which is Android API & Application Compatibility Test, on August of 2019. This CTS approval ensures that LG Interactive display supports stable work on Android OS.

USB Block

The USB Block Mode that helps secure and prevent data from being copied into unauthorized devices in advance, which is essential for being used in space where security is critical.

Secure Mode

Secure Mode blocks unauthorized contents to be shown via sharing screen function in various devices. The preloaded applications related to share screens will be hidden from menu. Secured mode disables screen mirroring options for SSP (Screen Share Pro). It helps prevent unauthorized access to your IDB.

KEY FEATURE

HW - Internal Memory :  16GB
HW - Wi-Fi - Built-in :  Yes (Slot type)
HW - Power Indicator :  Yes
HW - Local Key Operation :  Yes
SW - webOS ver :  Android 8.0
SW - Screen Share :  Yes (Screenshare pro)
Power Supply :  AC 100-240 V ~, 50/60 Hz
Power Type :  Built-In Power
Speaker :  Yes
OPS Type Compatible :  Yes (Slot)
OPS Power Built In :  Yes
Basic :  Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Operation Temperature :  0 °C to 40 °C
Operation Humidity :  10 % to 80 %

SPECIAL FEATURE

Touch - Available object size for touch :  Ø3 mm ↑
Touch - Reponse Time(PC Win10) :  60ms ↓ (Android), 100ms ↓ (Windows)
Touch - Accuracy :  ±1.5mm
Touch - Interface :  USB2.0

Touch - Protection Glass Thickness :  4T (Anti-Glare)
Touch - Protection Glass Transmission :  87%
Touch - Operating System Support :  Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Touch - Multi touch point :  Max 20 Points

LG B-Series Model Price

LG-65TR3BF Model"

Price ₹165,200.00

LG 75TR3BF Model"

Price ₹265,500.00

LG 86TR3BF Model"

Price ₹401,200.00
